2-way Control Valves, DN 15/4-50mm, Nodular Cast Iron

2.5.02 G1F

Approvals

Applications

  • compressed air
  • cooling
  • demi Water
  • heating
  • solar energy
  • steam

Art. No.

Description

Size

Item weight

PN

Type of connection
1-2410012 VALVE G1F DN15/4, EN FLANGES DN15/4 3.0 KGM PN 25 Flange
1-2410036 VALVE G1F DN15/4, JIS 16K DN15/4 3.0 KGM 16K JIS flange
1-2410037 VALVE G1F DN15/4, JIS 5K DN15/4 3.0 KGM 5K JIS flange
1-2410038 VALVE G1F DN15/4, ANSI 150 DN15/4 3.0 KGM Class 150 ANSI flange
1-2410039 VALVE G1F DN15/6, EN FLANGES DN15/6 3.0 KGM PN 25 Flange
1-2410040 VALVE G1F DN15/4, JIS 10K DN15/4 3.0 KGM 10K JIS flange
1-2410041 VALVE G1F DN15/6, ANSI 150 DN15/6 3.0 KGM Class 150 ANSI flange
1-2410042 VALVE G1F DN15/6, JIS 10K DN15/6 3.0 KGM 10K JIS flange
1-2410044 VALVE G1F DN15/6, JIS 5K DN15/6 3.0 KGM 5K JIS flange
1-2410045 VALVE G1F DN15/9, JIS 16K DN15/9 3.1 KGM 16K JIS flange
1-2410046 VALVE G1F DN15/9, JIS 5K DN15/6 3.0 KGM 5K JIS flange
1-2410047 VALVE G1F DN15/9, EN FLANGES DN15/9 3.1 KGM PN 25 Flange
1-2410049 VALVE G1F DN15/9, ANSI 150 DN15/9 3.1 KGM Class 150 ANSI flange
1-2410050 VALVE G1F DN15/9, JIS 10K DN15/9 3.1 KGM 10K JIS flange
1-2410051 VALVE G1F DN15/12, ANSI 150 DN15/12 3.1 KGM Class 150 ANSI flange
1-2410052 VALVE G1F DN15/12, JIS 10K DN15/12 3.1 KGM 10K JIS flange
1-2410054 VALVE G1F DN20, ANSI 150 DN20 4.2 KGM Class 150 ANSI flange
1-2410055 VALVE G1F DN15/12, EN FLANGES DN15/12 3.1 KGM PN 25 Flange
1-2410056 VALVE G1F DN15/12, JIS 16K DN15/12 3.1 KGM 16K JIS flange
1-2410057 VALVE G1F DN 15/12, JIS 5K DN15/12 3.1 KGM 5K JIS flange
1-2410063 VALVE G1F DN15, EN FLANGES DN15 3.1 KGM PN 25 Flange
1-2410064 VALVE G1F DN15, JIS 10K DN15 3.1 KGM 10K JIS flange
1-2410065 VALVE G1F DN15, ANSI 150 DN15 3.1 KGM Class 150 ANSI flange
1-2410066 VALVE G1F DN15, JIS 16K DN15 3.1 KGM 16K JIS flange
1-2410067 VALVE G1F DN15, JIS 5K DN15 3.1 KGM 5K JIS flange
1-2410071 VALVE G1F DN20, EN FLANGES DN20 4.2 KGM PN 25 Flange
1-2410071G VALVE G1F DN20 CUT-THROUGH 42.0 KGM PN 25
1-2410096 VALVE G1F DN25, JIS 16K DN25 5.5 KGM 16K JIS flange
1-2410097 VALVE G1F DN25, JIS 5K DN25 5.5 KGM 5K JIS flange
1-2410098 VALVE G1F DN25, EN FLANGES DN25 5.5 KGM PN 25 Flange
1-2410101 VALVE G1F DN32, EN FLANGES DN32 8.1 KGM PN 25 Flange
1-2410102 VALVE G1F DN32, JIS 5K DN32 8.1 KGM 5K JIS flange
1-2410103 VALVE G1F DN32, JIS 16K DN32 8.1 KGM 16K JIS flange
1-2410128 VALVE G1F DN40, EN FLANGES DN40 9.7 KGM PN 25 Flange
1-2410129 VALVE G1F DN40, JIS 16K DN40 9.7 KGM 16K JIS flange
1-2410130 VALVE G1F DN40, JIS 5K DN40 9.7 KGM 5K JIS flange
1-2410136 VALVE G1F DN50, EN FLANGES DN50 14.0 KGM PN 25 Flange
1-2410137 VALVE G1F DN50, JIS 16K DN50 14.0 KGM 16K JIS flange
1-2410138 VALVE G1F DN50, JIS 5K 14.0 KGM 5K JIS flange
1-2410151 VALVE G1F DN20, JIS 5K DN20 4.2 KGM 5K JIS flange
1-2410152 VAVLE G1F DN20, JIS 16K DN20 4.2 KGM 16K JIS flange
1-2410153 VALVE G1F DN20 JIS 10K 42.0 KGM 10K JIS flange
1-2410154 VALVE G1F DN20, ANSI 150 DN20 4.2 KGM Class 150 ANSI flange
1-2410155 VALVE G1F DN25, JIS 10K DN25 5.5 KGM 10K JIS flange
1-2410156 VALVE G1F DN25, ANSI 150 DN25 5.5 KGM Class 150 ANSI flange
1-2410157 VALVE G1F DN32, JIS 10K DN32 8.1 KGM 10K JIS flange
1-2410158 VALVE G1F DN32, ANSI 150 DN32 8.1 KGM Class 150 ANSI flange
1-2410159 VALVE G1F DN40, JIS 10K DN40 9.7 KGM 10K JIS flange
1-2410160 VALVE G1F DN40, ANSI 150 DN40 9.7 KGM Class 150 ANSI flange
1-2410161 VALVE G1F DN50, JIS 10K DN50 14.0 KGM 10K JIS flange
1-2410162 VALVE G1F DN50, ANSI 150 DN50 14.0 KGM Class 150 ANSI flange
1-2410284 VALVE G1F DN15/6 FLANGES R13-V13 31.0 KGM PN 25 Flange
1-2410421 VALVE G1F DN50 INCLUDE S25SC+H 25.0 KGM PN 25 Flange
1-2410540 VALVE G1F DN32/25 81.0 KGM PN 25 Flange
1-2410586 VALVE G1F DN20/9 42.0 KGM PN 25 Flange
1-2410608 VALVE G1F DN15 ANSI B16.5 Cl300 31.0 KGM Class 300 ANSI flange
1-2410632 VALVE G1F DN32/15 81.0 KGM PN 25 Flange
